BioLink™ Bluetooth Wireless Communication
RF data radio networking tools
Connect your CBRN International instruments and software together with BioLink Bluetooth RF data radio technology.
With BioLink, you can maximize the capabilities your CBRN International instruments. Sensors and samplers can communicate wirelessly with one another, and also with monitoring software installed on a PC.
The BioLink device draws all of its operating power from the RS-232 data interface on CBRN International samplers and detection instruments, and has all radio functions built-in. The BioLink connected to the PC can be powered from any USB port directly, or via a supplied USB cable if an RS-232 connector-equipped BioLink model is used at the PC.
Each device has a pairing button and LED that provides a quick and easy method for establishing a trusted device Bluetooth connection without the need for a PC. A four position dip switch sets the baud rate and enables or disables hardware handshaking. In a few minutes the wireless connection setup is complete.
- No bulky cables to fail
- Extends the utility of instruments
- Instruments are fully mobile
- Rapid system setup
- Easy system reconfiguration
- Lower installed system costs
|Bluetooth specification:||Bluetooth v2.0 + EDR.|
|Max data transfer rate:||3 MBPS with USB style
921.6 MBPS with RS-232 style
|Working distance:||+1dBi Dipole Antenna (100 meter range)
+3dBi Dipole Antenna (200 meter range)
+5dBi Dipole Antenna (400 meter range)
+9dBi Patch Antenna with separate cable connection (1,000 meter range)
|Operating temperature:||-20°C to 70°C|
|Storage temperature:||-40°C to 85°C|
|Size:||76 x 31 x 16 mm (RS-232)
72 x 22 x 10 mm (USB)
|Computer OS support (USB only):||Windows 2000/XP/Vista; Linux; MAC OS X (MAC OS X driver required)|
|Approvals:||RS-232: CE, FCC, TELEC, MIC USB: CE, FCC, TELEC, KCC,Bluetooth SIG|
CBRN International reserves the right to change specifications without prior notice.
